Pepperl+Fuchs KFD2-SR2-EX1.W.LB high-performance 1-channel isolated barrier and switch amplifier
Product Details:
Manufacturer : Pepperl + Fuchs
Product No. : KFD2-SR2-EX1.W.LB
https://www.achievers-automation.com More Products
Reliable Industrial Component Sourcing for Enterprises
This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.
To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.
The Pepperl+Fuchs KFD2-SR2-EX1.W.LB is a high-performance 1-channel isolated barrier and switch amplifier, designed to deliver reliable signal processing and safety in industrial environments. As a leading product from Pepperl+Fuchs—a global pioneer in industrial sensor and automation technology—the KFD2-SR2-EX1.W.LB combines robust construction, precise functionality, and compliance with international safety standards, making it ideal for critical industrial applications that require secure signal isolation and fault detection.
Detail:
|
Specification Category
|
Details for Pepperl+Fuchs KFD2-SR2-EX1.W.LB
|
|
Signal Type
|
Digital Input
|
|
Functional Safety
|
Safety Integrity Level (SIL): 2; Systematic Capability (SC): 3 (per IEC/EN 61508:2010)
|
|
Power Supply
|
Rated Voltage (UR): 19 ... 30 V DC; Ripple: ≤ 10%; Rated Current (IR): ≤ 45 mA; Power Dissipation: ≤ 0.9 W
|
|
Input Parameters
|
Connection: Field side (Terminals 1+, 2+, 3-); Open Circuit Voltage/Short-Circuit Current: Approx. 8 V DC / 8 mA; Switching Point: 1.2 ... 2.1 mA; Switching Hysteresis: Approx. 0.2 mA
|
|
Line Fault Detection
|
Breakage: I ≤ 0.1 mA; Short-Circuit: I > 6 mA
|
|
Pulse/Pause Ratio
|
Minimum 20 ms / Minimum 20 ms
|
|
Switching Frequency
|
≤ 10 Hz
|
|
Specification Category
|
Details for Pepperl+Fuchs KFD2-SR2-EX1.W.LB
|
|
Mounting
|
35 mm DIN mounting rail (per EN 60715:2001)
|
|
Degree of Protection (IP Rating)
|
IP20 (per IEC 60529:1989 + A1:1999 + A2:2013)
|
|
Operating Temperature Range
|
-20 °C to +60 °C
|
|
Weight
|
0.12 kgs
|
|
Galvanic Isolation
|
Reinforced insulation (per IEC/EN 61010-1); Rated Insulation Voltage: 300 V eff (input/output, input/power, output/power, output/output)
|
|
Mechanical Life
|
10⁷ switching cycles
|
|
Compliance & Certifications
|
EMC: Directive 2014/30/EU (EN 61326-1:2013, NE 21:2017, EN 61326-3-1:2017, EN IEC 61326-3-2:2018); Low Voltage: Directive 2014/35/EU (EN 61010-1:2010 + A1:2019 + A1:2019/AC:2019)
|
