Fischer 175 543 074 Right-Angle PCB Male Header Connector
Product Details:
Manufacturer : Fischer
Product No. :175 543 074
https://www.achievers-automation.com More Products
Reliable Industrial Component Sourcing for Enterprises
This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.
To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.
The Fischer 175 543 074 is a right-angle male pin header from the Fischer S2L 3.5 connector family. It features a standardized 3.5 mm contact pitch and through-hole soldering termination for PCB mounting.
This connector matches S2L female pluggable terminal blocks, enabling fast assembly, testing and module replacement without re-soldering. The compact right-angle layout optimizes limited vertical space inside electrical enclosures. The glass-filled PA insulator meets high flame resistance standards, while tin-plated copper alloy pins deliver stable long-term electrical contact under industrial vibration and temperature fluctuations. Widely used for analog/digital signal transmission, low-power DC wiring for PLC, sensor modules and drive equipment.
Detail:
| Parameter |
Specification |
| Model Number |
175 543 074 |
| Brand |
Fischer Elektronik |
| Series |
S2L 3.5 PCB Plug-In Connector |
| Pitch |
3.5 mm |
| Termination Type |
Right Angle Through-Hole Soldering |
| Rated Voltage |
160 V |
| Rated Current per Pin |
8 A |
| Test Voltage |
2000 V AC |
| Contact Material |
Copper Alloy |
| Contact Plating |
Tin Plating |
| Contact Resistance |
≤15 mΩ |
| Insulation Resistance |
≥10⁹ Ω |
| Overvoltage Category |
II |
| Pollution Degree |
2 |
| Compatible Mating Part |
S2L 3.5 female plug terminal blocks |
| Parameter |
Specification |
| Insulator Material |
Glass-Filled Polyamide PA, UL94 V-0 |
| Mounting Style |
Horizontal right-angle PCB mounting |
| Operating Temperature Range |
-40 °C ~ +105 °C |
| Short-Term Solder Temperature |
260 °C (max. 10 s) |
| Storage Temperature |
-45 °C ~ +110 °C |
| Vibration Resistance |
10–2000 Hz, 10 g (IEC 60068-2-6) |
| Shock Resistance |
50 g, 6 ms (IEC 60068-2-27) |
| Flammability Class |
UL94 V-0 |
| Protection Class |
IP20 (indoor cabinet installation) |
| Compliance Standards |
IEC 61984, RoHS, CE |
| Installation Orientation |
Horizontal right angle PCB layout |
