BALLUFF EL1904 0000 TwinSAFE EtherCAT Digital Input Terminal
Product Details:
Manufacturer : Balluff
Product No. : EL1904 0000
https://www.achievers-automation.com More Products
Reliable Industrial Component Sourcing for Enterprises
This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.
To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.
The Balluff EL1904 0000 is a safety-rated EtherCAT terminal integrated with TwinSAFE technology, designed for connecting 24 V DC safety sensors and contact signals to EtherCAT industrial bus systems. This EL1904 0000 variant provides four independent fail-safe digital input channels, transmitting safety data via FSoE (FailSafe over EtherCAT) protocol to TwinSAFE logic controllers.
Detail:
| Parameter Category |
EL1904 0000 Standard Configuration Value |
| Manufacturer |
Balluff GmbH |
| Full Model Code |
EL1904 0000 |
| Product Series |
TwinSAFE EtherCAT Safety I/O Terminals |
| Module Type |
4-Channel Fail-Safe Digital Input Terminal |
| Bus Interface |
EtherCAT, FSoE Safety Protocol |
| Housing Dimensions (W × H × D) |
12 mm × 100 mm × 68 mm |
| Mounting Method |
DIN rail stacking via E-bus backplane connector |
| Wiring Terminal Type |
Spring-cage screwless terminals |
| Supported Wire Cross Section |
0.08 mm² ~ 2.5 mm² solid/flexible wire |
| Wire Stripping Length |
8–9 mm |
| Unit Net Weight |
50 g |
| Channel LED Indicator |
Individual status LED per input channel |
| Bus & Fault Diagnostic LEDs |
Dedicated RUN, ERR, SAFE status indicators |
| Terminal Stacking Feature |
Double slot key interlock for secure module alignment |
| Performance Item |
Rated Technical Parameter |
| Input Signal Voltage |
24 V DC nominal safety sensor supply |
| Number of Safe Input Channels |
4 isolated fail-safe digital inputs |
| E-bus Current Consumption |
Typ. 200 mA |
| Max Power Contact Load |
10 A total group current |
| Typical Input Response Time |
4 ms |
| Configurable Fault Watchdog Delay |
User-programmable safety response timeout |
| Safety Certification |
SIL3 (IEC 61508), Cat.4 / PL e (EN ISO 13849-1) |
| Operating Ambient Temperature |
-20 °C ~ +60 °C horizontal mounting |
| Storage Temperature Range |
-40 °C ~ +85 °C |
| Permissible Relative Humidity |
5% – 90%, non-condensing |
| Ingress Protection Class |
IP20 (control cabinet installation only) |
| Electromagnetic Compliance |
EN 61000-6-2, EN 61000-6-3 industrial EMC |
| Protection Functions |
Input reverse polarity protection, short-circuit detection |
| Supported Signal Evaluation Modes |
Single-channel monitoring, dual-channel cross-check safety mode |
| Conformity Standards |
CE, UKCA, RoHS compliant |
