SICK GTB6-P1231 Miniature Background Suppression Photoelectric Sensor
Product Details:
Manufacturer : Sick
Product No. :GTB6-P1231
https://www.achievers-automation.com More Products
Reliable Industrial Component Sourcing for Enterprises
This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.
To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.
The SICK GTB6-P1231 (factory article number 1074135) is a compact rectangular diffuse photoelectric sensor with integrated background suppression technology, belonging to SICK’s industrial G6 miniature sensor series. Designed for stable object detection independent of varying background reflectance, this sensor adopts PinPoint visible red LED light source, supporting an adjustable sensing range of 5 mm to 400 mm, with a standard effective detection window of 50 mm–220 mm for standard white reflective targets (DIN 5033, 90% remission).
Description:
| Parameter Item |
Official Technical Value |
| Brand |
SICK |
| Full Model |
GTB6-P1231 |
| Factory Article Number |
1074135 |
| Product Series |
G6 Miniature Photoelectric Sensor |
| Detection Principle |
Diffuse reflection with background suppression |
| Overall Dimensions (W × H × D) |
12 mm × 31.5 mm × 21 mm |
| Housing Material |
Reinforced industrial plastic |
| Light Source |
PinPoint visible red LED |
| Wavelength |
625 nm |
| Light Spot Size (100 mm distance) |
Ø 6 mm |
| Sensing Adjustment Method |
Mechanical spindle, 5 full turns |
| Electrical Connection |
Fixed 2 m 3-wire cable |
| Protection Class |
IP67 |
| Operating Ambient Temperature |
-25 °C ~ +55 °C |
| Storage Temperature Range |
-40 °C ~ +70 °C |
| Net Weight |
60 g |
| Average LED Service Life (25°C) |
100,000 h |
| Certifications |
CE, cULus, UKCA, ACMA, China RoHS, DIN EN 62471 |
| UL File Reference |
NRKH.E348498 & NRKH7.E348498 |
| ECLASS Classification Code |
27270901 |
| Electrical Parameter |
Rated Performance Value |
| Operating Supply Voltage (Ub) |
10 VDC ~ 30 VDC |
| Permissible Residual Ripple |
± 10% of nominal supply voltage |
| Quiescent Current Consumption |
32 mA |
| Insulation Protection Class |
III |
| Max Adjustable Sensing Distance |
5 mm – 400 mm |
| Standard Effective Sensing Range |
50 mm – 220 mm (90% remission white target) |
| Digital Output Type |
PNP transistor output |
| Switching Mode |
Selectable Light Switching / Dark Switching |
| Max Output Load Current |
≤ 100 mA |
| Output Low Signal Voltage Drop |
≤ 3 V |
| Response Time (Resistive Load) |
< 1.2 ms |
| Maximum Switching Frequency |
500 Hz (1:1 light-dark duty cycle) |
| Built-in Circuit Protections |
Reverse polarity, overload, short-circuit protection |
| Temperature Drift Tolerance After Calibration |
± 10 °C stable detection |
| Max Permissible Surge Current |
8 A short-circuit threshold |
| Rated Utilization Category |
DC-13 industrial control circuit |
BRAND
SICK is a German brand founded in 1946, named after its founder, Dr. Erwin Sick. The company's headquarters is located in Waldkirch, a city in southwestern Germany. SICK is one of the international leading manufacturers in sensor technology and analytical instrumentation systems and holds a significant position in the field of industrial automation.
SICK's product range includes various types of sensors, encoders, switches, connectors, cables, photoelectric sensors, servo encoders, fiber optic sensors, laser scanners, safety switches, proximity sensors, and more. Additionally, it produces gas analyzers, flow sensors, and inclination sensors. These devices are widely used across various industries, such as packaging, food and beverage, machine tools, automotive manufacturing, logistics, airport facilities, electronics, and textiles.
Achievers Automation Limited has more than 10 years experience in the market of Industrial Automation, specialized in reselling factory sealed Probe, Sensor, DCS,isolator barrier, HMI, PLC,Adapter,Profibus connector and cable from Brands as BENTLY NEVADA, E+H, MTL, AB, Pepperl+Fuchs, YOKOGAWA, ASCO, Schneider, Lenze, Pro-face, Mitsubishi, Omron, Lenze, Delta, IFM etc. If you have any request, please do not hesitate to contact us.
Below are the TOP BRANDS we handle in the past 12 years:
FAQ of Achievers
Q:Are the Products Genuine OEM Units?
A: These items have been certified by Achievers Automation Limited to be genuine OEM Units obtained through OEM or independent third-party channels.
Q:How will you arrange shipment?
A: We can arrange shipment based on your request. We have cooperated forwader who can arrange shipment via FedEx, DHL,TNT with good price.
Q:What is the warranty of goods?
A: One-year Warranty.
