Pepperl+Fuchs LB5105A Module Thermocouple Converter with Backplane Bus Connection and 0.75 W Power Dissipation

Pepperl+Fuchs Thermocouple Converter LB5105A

Slots
Occupied slots		2
Supply
Connection		backplane bus
Rated voltage		12 V DC , only in connection with the power supplies LB9***
Power dissipation		0.75 W
Power consumption		0.75 W
Internal bus
Connection		backplane bus
Interface		manufacturer-specific bus to standard com unit
Input
Compensation (reference junction CJC)		internal cold junction compensation or external cold junction
temperature input
Number of channels		4
Suitable field devices
	Field device [2]	Thermocouple
	Field device [4]	mV source
Suitable sensors
	Sensor	thermocouples U, B, E, T, K, S, R, L, J, N, Pallaplat and mV sources
Connection		channel I: 1+, 2-; channel II: 5+, 6-; channel III: 9+, 10-; channel IV: 13+, 14-
Measuring range		-65 ... 75 mV with LFD , -75 ... 75 mV without LFD
Smallest span		5 mV for 0.1 % accuracy
Linearity error		0.1 %
Conversion time		max. 300 ms (4 channels) without LFD max. 600 ms (4-channel) with LFD
Compensation (reference junction CJC)		internal cold junction compensation or external cold junction
Line fault detection		can be switched on/off for each channel via configuration tool ,
	Open-circuit	> 1 kΩ
Transfer characteristics
Deviation
	Influence of ambient temperature	max. 0,1 %/10 K
Indicators/settings
LED indication		Power LED (P) green: supply Status LED (I) red: line fault (collective alarm) , red flashing: communication error
Coding		optional mechanical coding via front socket
Directive conformity
Electromagnetic compatibility
	Directive 2014/30/EU	EN 61326-1:2013
Conformity
Electromagnetic compatibility		NE 21
Degree of protection		IEC 60529
Environmental test		EN 60068-2-14
Shock resistance		EN 60068-2-27
Vibration resistance		EN 60068-2-6
Damaging gas		EN 60068-2-42
Relative humidity		EN 60068-2-78
Ambient conditions
Ambient temperature		-40 ... 60 °C (-40 ... 140 °F)
Storage temperature		-40 ... 85 °C (-40 ... 185 °F)
Relative humidity		95 % non-condensing
Altitude		max. 2000 m
Shock resistance		shock type I, shock duration 11 ms, shock amplitude 15 g, number of shocks 18
Vibration resistance		frequency range 10 ... 150 Hz; transition frequency: 57.56 Hz, amplitude/acceleration ± 0.075 mm/1 g; 10 cycles frequency range 5 ... 100 Hz; transition frequency: 13.2 Hz amplitude/acceleration ± 1 mm/0.7 g; 90 minutes at each resonance
Damaging gas		designed for operation in environmental conditions acc. to ISA-S71.04-1985, severity level G3
Mechanical specifications
Degree of protection		IP20 when mounted on backplane
Connection		removable front connector with screw flange (accessory) wiring connection via spring terminals (0.14 ... 1.5 mm2) or screw terminals (0.08 ... 1.5 mm2)
Mass		approx. 150 g
Dimensions		32.5 x 100 x 102 mm (1.28 x 3.9 x 4 inch)
Data for application in connection with hazardous areas
EU-type examination certificate		PTB 03 ATEX 2042 X
	Marking	II (1)G [Ex ia Ga] IIC II (1)D [Ex ia Da] IIIC I (M1) [Ex ia Ma] I
Input
	Voltage	1 V
	Current	71 mA
	Power	62 mW (trapezoid characteristic curve)
Certificate		PF 08 CERT 1234 X
	Marking	II 3 G Ex nA IIC T4 Gc
Galvanic isolation
	Input/input	functional insulation acc. to IEC 60664-1:2007, rated insulation voltage 50 V, testing voltage 500 V
	Input/power supply, internal bus	safe electrical isolation acc. to EN 60079-11, voltage peak value 375 V
Directive conformity
	Directive 2014/34/EU	EN IEC 60079-0:2018+AC:2020 EN 60079-11:2012 EN 60079-15:2010
International approvals
ATEX approval		PTB 03 ATEX 2042 X
UL approval		E106378
	Control drawing	116-0322
IECEx approval
	IECEx certificate	IECEx BVS 09.0037X
	IECEx marking	Ex nA [ia Ga] IIC T4 Gc [Ex ia Da] IIIC [Ex ia Ma] I
General information
System information		The module has to be mounted in appropriate backplanes (LB9***) in Zone 2 or outside hazardous areas. Here, observe the corresponding declaration of conformity. For use in hazardous areas (e. g. Zone 2, Zone 22 or Div. 2) the module must be installed in an appropriate enclosure.
Supplementary information		EC-Type Examination Certificate, Statement of Conformity, Declaration of Conformity, Attestation of Conformity and instructions have to be observed where applicable. For information see www.pepperl-fuchs.com.
