E+H FTS20 Liquifloat Float Point Level Switch
Product Details:
Manufacturer : Endress+Hauser
Product No. : E+H FMR50-39A7/0
https://www.achievers-automation.com More Products
This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.
To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.
The E+H FMR50-39A7/0 is a Micropilot FMR50 series free-space radar level transmitter manufactured by Endress+Hauser, designed for continuous non-contact level monitoring of liquids, slurries and pastes in standard industrial storage tanks, utility vessels and process reservoirsEndress+Ha....
Operating on 26GHz K-band radar principle, this FMR50-39A7/0 variant eliminates measurement interference caused by vapor, temperature fluctuations, foam and gas blankets above the liquid surface. It adopts an encapsulated PVDF horn antenna with excellent chemical resistance, paired with 4–20mA HART two-wire communication for seamless PLC system integration. Built-in HistoROM memory automatically stores device configuration, calibration data and diagnostic logs for fast commissioning and predictive maintenance
Endress+Ha....
Detail:
| Parameter Category |
FMR50-39A7/0 Standard Configuration Value |
| Brand Manufacturer |
Endress+Hauser (E+H) |
| Full Model Code |
FMR50-39A7/0 |
| Product Series |
Micropilot FMR50 Free-Space Radar Level Transmitter |
| Measuring Frequency |
26GHz K-band radar |
| Max Measuring Range |
30 m (98 ft) standard range |
| Antenna Type |
Encapsulated PVDF Cladded Horn Antenna |
| Process Connection |
1½" MNPT External Thread |
| Primary Wetted Materials |
PVDF, Viton Fluoroelastomer Seal, PBT |
| Housing Material |
Die-cast Aluminum with Polyester Coating |
| Ingress Protection |
IP66 / IP68, NEMA 4X |
| Local Display |
4-line LCD Digital Display with 4 operation keys |
| Communication Protocol |
2-wire 4–20mA HART 7 |
| Optional Function |
Bluetooth SmartBlue wireless commissioning |
| Overall Mounting Reference Height |
137.9 mm (DN80 horn) |
| Net Weight |
2.8 kg |
| Performance Item |
Rated Technical Parameter |
| Measurement Accuracy |
±2 mm (0.08 in) full range |
| Process Liquid Temperature |
-40 °C ~ +130 °C (-40 °F ~ +266 °F) |
| Allowable Process Pressure |
-1 bar vacuum ~ +3 bar gauge (-14.5 ~ +43.5 psi) |
| Ambient Operating Temperature |
-40 °C ~ +80 °C (-40 ~ +176 °F) |
| Power Supply |
10.5 V DC ~ 35 V DC two-wire loop power |
| HART Loop Current Output |
4 mA (empty) ~ 20 mA (full) |
| Programmable Switch Points |
Max 2 independent level alarm points |
| Switching Delay Range |
0 ~ 100 seconds user configurable |
| Safety Integrity Level |
SIL2 single device; SIL3 with redundant installation |
| Global Compliance Certifications |
ATEX II 1/2G Ex ia IIC T6, IECEx, FM, CSA C/US, EAC, NEPSI, WHG Overfill Approval |
| Interference Immunity |
Resistant to vapor, foam, turbulence, tank internal structures |
| Diagnostic Functions |
Echo quality monitoring, antenna contamination alert, loop fault detection |
| Calibration Method |
Tank height auto-mapping, no liquid medium calibration required |
| RoHS Compliance |
Fully compliant with EU RoHS 2 hazardous substance restrictions |
