E+H FTM42-AN42A Soliphant T Vibronic Point Level Switch
Product Details:
Manufacturer : Endress+Hauser
Product No. : FTM42-AN42A
https://www.achievers-automation.com More Products
This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.
To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.
The E+H FTM42-AN42A is a robust vibronic tuning-fork point level switch from Endress+Hauser Soliphant T FTM42 product line, engineered for reliable high/low level detection of fine and coarse bulk solids in industrial silos, hoppers, conveyors and storage vessels. The tuning fork measuring principle eliminates interference from medium conductivity, material buildup, turbulence, air bubbles or external vibration, delivering stable measurement without regular calibration.
Detail:
| Parameter Category |
Specification Value of FTM42-AN42A |
| Manufacturer |
Endress+Hauser (E+H) |
| Full Model Code |
FTM42-AN42A |
| Product Series |
Soliphant T FTM42 Vibronic Level Switch |
| Detection Medium |
Bulk solids (powder, granules, pellets) |
| Hazardous Area Approval |
A = Non-hazardous industrial area |
| Process Connection Code |
N = ANSI NPT 1½" Thread, 316L stainless steel |
| Electronics Output Code |
4 = DPDT Relay Output (19–253 V AC / 55 V DC) |
| Housing & Cable Entry Code |
2 = F16 Polyester Housing, IP66/IP67, NEMA4X, M20 Cable Gland |
| Additional Fitting Code |
A = Standard basic version |
| Sensing Principle |
Vibronic tuning fork resonance shift |
| Minimum Medium Density |
200 g/L |
| Standard Probe Length |
225 mm |
| Approximate Overall Dimensions |
80 mm × 80 mm × 379 mm |
| Net Weight |
4.0 kg |
| Performance Item |
Rated Technical Data
|
| Process Temperature Range |
-40 °C ~ +150 °C (-40 °F ~ +302 °F) |
| Max Allowable Process Pressure |
25 bar absolute |
| Ambient Operating Temperature |
-30 °C ~ +70 °C |
| Ingress Protection Grade |
IP66 / IP67, NEMA 4X |
| Supply Voltage Range |
19 V AC Min ~ 253 V AC Max |
| Switch Contact Type |
DPDT relay contact |
| Response Time |
≤ 5 ms |
| Self-Monitoring Function |
Continuous fork frequency monitoring, fault signal trigger |
| Compliance Certifications |
ATEX, IECEx, FM, CSA C/US, EAC, NEPSI |
| Wetted Material |
316L stainless steel |
| Housing Material |
Reinforced glass fiber polyester |
| Cable Entry |
M20 standard cable gland |
| Measurement Interference Resistance |
Not affected by buildup, vibration, flow, air bubbles |
Brand
E+H is a global leader in providing measurement instruments, services, and solutions for the process and laboratory industries. Since its founding in 1953, the company has been committed to enhancing production efficiency, safety, and sustainability through innovative technologies. E+H’s product portfolio covers a wide range of areas, including flow measurement, level measurement, pressure and temperature measurement, analytical instrumentation, and data management. Its solutions are widely used in industries such as chemicals, food and beverage, oil and gas, power generation, and water and wastewater treatment.
Company Introduction:
Achievers Automation Limited has more than 10 years experience in the market of Industrial Automation, specialized in reselling factory sealed Probe, Sensor, DCS,isolator barrier, HMI, PLC,Adapter,Profibus connector and cable from Brands as BENTLY NEVADA, E+H, MTL, AB, Pepperl+Fuchs, YOKOGAWA, ASCO, Schneider, Lenze, Pro-face, Mitsubishi, Omron, Lenze, Delta, IFM etc. If you have any request, please do not hesitate to contact us.
Below are the TOP BRANDS we handle in the past 14 years:
FAQ of Achievers
Q:Are the Products Genuine OEM Units?
A: These items have been certified by Achievers Automation Limited to be genuine OEM Units obtained through OEM or independent third-party channels.
Q:How will you arrange shipment?
A: We can arrange shipment based on your request. We have cooperated forwader who can arrange shipment via FedEx, DHL,TNT with good price.
Q:What is the warranty of goods?
A: One-year Warranty.
