E+H FMU40-ARH1A2 Prosonic M Ultrasonic Level Transmitter
Product Details:
Manufacturer : Endress+Hauser
Product No. : FMU40-ARH1A2
https://www.achievers-automation.com More Products
This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.
To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.
The Endress+Hauser (E+H) FMU40-ARH1A2 belongs to the Prosonic M FMU40 compact ultrasonic transmitter series, designed for continuous non-contact level monitoring of liquids, slurries, pastes and coarse bulk solids. Built with time-of-flight ultrasonic measuring technology and integrated temperature compensation sensor, FMU40-ARH1A2 automatically corrects sound velocity drift caused by ambient and process temperature fluctuations to deliver stable, repeatable readingsEndress+Ha...
Detail:
| Specification Item |
FMU40-ARH1A2 Standard Parameter |
| Product Series |
Endress+Hauser Prosonic M FMU40 |
| Full Model Code |
FMU40-ARH1A2 |
| Measuring Principle |
Ultrasonic Time-of-Flight (ToF) |
| Measurable Media |
Liquids, slurries, pastes, coarse bulk solids |
| Maximum Measuring Range |
Liquids: 5 m / 16 ft; Solids: 2 m / 6.6 ft |
| Blocking Distance |
0.25 m / 0.8 ft |
| Measurement Accuracy |
±2 mm or ±0.2% of full measuring range |
| Measured Value Resolution |
1 mm / 0.04 in |
| Internal Temperature Compensation |
Integrated built-in temperature sensor |
| Linearization Points |
Up to 32 configurable breakpoints |
| Pulse Update Frequency |
0.5 Hz (2-wire HART version) |
| Reference Calibration Condition |
20°C, 1013 mbar abs., calm liquid surface |
| Signal Processing |
Automatic echo suppression, tank interference filtering |
| Configuration Category |
FMU40-ARH1A2 Standard Details |
| Wetted Sensor Material |
PVDF (fully sealed, chemical resistant) |
| Process Connection |
G 1½" ISO 228 Thread (compatible with NPT 1½") |
| Sealing Material |
EPDM standard seal |
| Instrument Housing |
Coated die-cast aluminum F12 housing |
| Ingress Protection Grade |
IP68 / NEMA 6P |
| Power Supply Mode |
2-wire loop-powered 4–20mA HART |
| Operating Voltage Range |
14 VDC to 36 VDC terminal voltage |
| Signal Output Protocol |
4–20 mA analog + HART 7 communication |
| Cable Gland Standard |
M20×1.5 metal cable entry |
| Process Temperature Range |
-40 °C to +80 °C (-40 °F to +176 °F) |
| Process Absolute Pressure |
0.7 bar abs to 3 bar abs (10–44 psi) |
| Ambient Operating Temperature |
-40 °C to +80 °C (-40 °F to +176 °F) |
| Storage Temperature |
-40 °C to +80 °C |
| Global Safety Certifications |
ATEX II 1/2G Ex ia IIC T6, IECEx, FM, CSA, NEPSI |
| Vibration Compliance |
DIN EN 60068-2-64 industrial vibration standard |
| EMC Compliance |
EN 61326 Class B industrial electromagnetic immunity |
| Display Configuration |
On-site 4-line multilingual LC display (7 selectable languages) |
Brand
E+H is a global leader in providing measurement instruments, services, and solutions for the process and laboratory industries. Since its founding in 1953, the company has been committed to enhancing production efficiency, safety, and sustainability through innovative technologies. E+H’s product portfolio covers a wide range of areas, including flow measurement, level measurement, pressure and temperature measurement, analytical instrumentation, and data management. Its solutions are widely used in industries such as chemicals, food and beverage, oil and gas, power generation, and water and wastewater treatment.
