E+H FCPS12D/E Flow Cell pH/ORP Sensor Holder
Product Details:
Manufacturer : Endress+Hauser
Product No. : FCPS12D/E
https://www.achievers-automation.com More Products
This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.
To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.
This flow cell assembly is purpose-built to accommodate standard E+H CPF, CPH series pH and ORP glass sensors with 12 mm outer diameter probe bodies. The integrated fluid flow chamber creates stable laminar flow around the sensor glass membrane, eliminating air bubble trapping and improving long-term measurement stability. Wetted surfaces adopt corrosion-resistant stainless steel construction with optional PTFE sealing components to resist acidic, alkaline and low-salinity aqueous media.
IP67 enclosure rating protects external wiring terminals against workshop dust, splash water and condensation. The modular split structure allows fast sensor replacement without full pipeline disassembly, reducing process downtime for maintenance. Compliant with IEC 60584, ISO 14644 cleanroom standards and global pressure vessel safety codes, FCPS12D/E units are deployed across water treatment, chemical processing, food & beverage, pharmaceutical and environmental monitoring analytical systems.
Detail:
| Parameter Item |
Standard Spec of E+H FCPS12D / FCPS12E Flow Cell Holder |
| Brand |
Endress+Hauser (E+H) |
| Full Model Code |
FCPS12D (Industrial Standard) / FCPS12E (Hygienic Polished) |
| Product Series |
FCPS Modular Immersion Flow Cell Sensor Holder |
| Compatible Sensor Outer Diameter |
12 mm standard pH/ORP probes (CPF/CPH series) |
| Internal Flow Chamber Type |
Laminar flow channel, anti-air-bubble design |
| Nominal Process Pressure Range |
0 ~ 10 bar (0 ~ 1.0 MPa) |
| Max Test Pressure |
15 bar (1.5 MPa) |
| Operating Medium Temperature |
0 ℃ ~ 80 ℃ continuous; FCPS12E SIP peak 135 ℃ short-term |
| Ambient External Temperature |
-20 ℃ ~ +60 ℃ |
| Ingress Protection Rating (Terminal Box) |
IP67 |
| Standard Process Connection Thread |
G1/2 female inlet / outlet ports |
| Drain Port Size |
G1/4 side flush drain port |
| Mounting Orientation |
Vertical immersion or horizontal inline pipeline installation |
| Surface Roughness (Wetted) |
FCPS12D Ra ≤ 3.2 μm; FCPS12E Ra ≤ 0.8 μm hygienic polish |
| Cleaning Compatibility |
FCPS12D: Manual chemical flush; FCPS12E: CIP / SIP sterilization cycles |
| Maximum Medium Flow Rate |
200 L/h stable laminar measurement flow |
| Terminal Cable Entry |
M16 cable gland for sensor cable routing |
| Mechanical Service Life |
≥ 10,000 sensor replacement cycles |
| Net Unit Weight |
0.95 kg (FCPS12D); 1.02 kg (FCPS12E polished variant) |
| Compliance Standards |
IEC 60584, ISO 14644, FDA compliant wetted materials (FCPS12E) |
| Component Name |
Raw Material Grade |
Functional Description for FCPS12D/E |
| Main Wetted Flow Cell Body |
AISI 316L Stainless Steel |
High corrosion resistance for acidic, alkaline aqueous media; FCPS12E precision internal polishing for sterile hygienic processes |
| Internal Sensor Lock Sleeve |
PTFE (Teflon) |
Low-friction sliding fit for sensor insertion, chemical inert to most process liquids |
| Process Port Sealing Gaskets |
EPDM standard / PTFE optional |
Replaceable sealing rings, media-resistant for long-term continuous operation |
| External Terminal Junction Box |
Reinforced PA66 Flame Retardant Plastic (UL94 V0) |
IP67 sealed housing, protects sensor cable wiring from dust and splash moisture |
| Junction Box Compression Cable Gland |
NBR Rubber Seal + Nickel-Plated Brass Thread |
M16 cable entry, adjustable clamping for different sensor cable outer diameters |
| Side Drain Valve Plug |
AISI 316L Stainless Steel + PTFE Seal |
Manual flush port for sediment removal without dismounting full flow cell |
| Sensor Retaining Lock Nut |
AISI 316 Stainless Steel |
Threaded lock to fix 12mm diameter pH/ORP probes, prevents vibration-induced sensor shift |
| Flow Guide Internal Baffles |
Integrated molded PTFE inserts |
Create uniform laminar flow around sensor glass membrane, eliminate bubble trapping |
| Mounting Base Lugs |
Cast AISI 316 Stainless Steel |
Integrated mounting feet for tank wall or pipeline bracket bolt installation |
| Insulating Terminal Partition |
Silicone-Free FR4 Plastic |
Electrical isolation for Memosens digital sensor wiring contacts inside junction box |
