Pepperl + Fuchs Rotation Speed Monitor KFU8-DW-1.D with ≤ 10 Hz Switching Frequency and 0.3 mm Target Size

Pepperl + Fuchs Rotation Speed Monitor KFU8-DW-1.D with ≤ 10 Hz Switching Frequency and 0.3 mm Target Size
Pepperl + Fuchs Rotation Speed Monitor KFU8-DW-1.D with ≤ 10 Hz Switching Frequency and 0.3 mm Target Size

Large Image :  Pepperl + Fuchs Rotation Speed Monitor KFU8-DW-1.D with ≤ 10 Hz Switching Frequency and 0.3 mm Target Size

Product Details:
Place of Origin: Germany
Brand Name: Pepperl + Fuchs
Model Number: Speed Monitor KFU8-DW-1.D
Document: Pepperl + Fuchs Rotation Sp....D.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Payment Terms: D/A
Contact Now
Detailed Product Description
Tightening Torque: 0.6 Nm Output Polarity: DC
Linearity Error: 0.1 % Construction Type: M12
Interface Type: RS-485 , 2-wire Multidrop Target Size: 0.3 Mm
Switching Frequency: ≤ 10 Hz Length: 63.5 Mm
Output Current: 4-20 MA
Highlight:

Pepperl Fuchs Rotation Speed Monitor

,

KFU8-DW-1.D Rotation Speed Monitor

Pepperl + Fuchs Rotation Speed Monitor KFU8-DW-1.D


Product Details:

Manufacturer : Pepperl + Fuchs

Product No. :  Rotation Speed Monitor KFU8-DW-1.D


Description:

Speed monitoring up to 40 kHz
< 1 pre-select value with relay output and LED indicator
< 2-, 3-, 4-wire and NAMUR sensors as well as rotary encoder
connectable
< Start-up delay
< Menu driven operation via 4 front keys
< Period measurement
< Output signal can be inverted
< Display devices can be set between 0.1 ... 2.5 sec


Technical Data
Functional safety related parameters
MTTFd 100 a
Supply
Rated voltage Ur 200 ... 230 V AC ; 100 … 130 V AC; 50/60 Hz
20 VDC ... 30 VDC
Fusing external fusing 4 A
Power consumption AC: < 5 VA
DC: < 5 W
Input 1
Connection terminals 8-, 9+
Connectable sensor types NAMUR sensors according to DIN EN 60947-5-6
Open loop voltage 8.2 V DC
Short-circuit current 6.5 mA
Switching point 1.2 ... 2.1 mA Switching hysteresis approx. 0.2 mA
Input frequency 0.002 ... 10000 Hz, pulse length/duration: ≥ 20μs
Impedance 1.2 kΩ
Input 2
Switching point high: 16 ... 30 V DC; max.10 mA due to integrated constant current sink; Ri ≅ 3 kΩ
low: 0 ... 6 V DC
Input frequency 0.002 ... 40000 Hz, pulse length/duration: ≥ 12μs
Connection terminals 7+, 13- sensor supply
terminals 14, 15 NPN/PNP input (galvanically isolated)
Connectable sensor types Two, three, or four-wire proximity switch, incremental rotary encoder, or externally
generated pulses 16 ... 30 V
Sensor supply 19 ... 28 V DC non-stabilised; ≤ 30 mA short-circuit protected
Input 3
Start-up override Triggering by external signal 16 ... 30 V or Place jumper between terminals 2/3 or by
switching on supply voltage (terminal 2 and terminal 3 permanently bridged)
Hold-up time 0.1 ... 999.9 s (External trigger signal)
Output
Relay 1 changeover contact
NO, NC, COM
Sensor supply 24 V DC ± 10 %, 30 mA , short-circuit protected
Contact loading 250 V AC/2 A/ cos φ ≥ 0.7
40 V DC/2 A
Delay ≤ 20 ms (incl. calculation time)
Mechanical life ≥ 30.000.000 switching cycles

Supply
Rated voltage  Ur 200 ... 230 V AC ; 100 … 130 V AC; 50/60 Hz
Fusing external fusing  4 A
Power consumption AC:  < 5 VA
DC:  < 5 W

 Pepperl + Fuchs Rotation Speed Monitor KFU8-DW-1.D with ≤ 10 Hz Switching Frequency and 0.3 mm Target Size 0

Pepperl + Fuchs Rotation Speed Monitor KFU8-DW-1.D with ≤ 10 Hz Switching Frequency and 0.3 mm Target Size 1

Pepperl + Fuchs Rotation Speed Monitor KFU8-DW-1.D with ≤ 10 Hz Switching Frequency and 0.3 mm Target Size 2

Brand

Pepperl + Fuchs, a globally renowned industrial brand, has long been at the forefront of industrial automation innovation. Since its establishment in 1945 in Mannheim, Germany, by Walter Pepperl and Ludwig Fuchs, it has transformed from a small radio - repair and transformer - manufacturing workshop into a multinational enterprise with a vast global presence.​
In 1958, Pepperl + Fuchs made a significant mark by inventing the world's first inductive proximity switch, revolutionizing object - position measurement, especially in packaging and filling systems. This success led to continuous expansion into sensing, intrinsic safety, and explosion - protection technologies. From the 1970s, the company set up subsidiaries worldwide for production and sales.

Pepperl + Fuchs Rotation Speed Monitor KFU8-DW-1.D with ≤ 10 Hz Switching Frequency and 0.3 mm Target Size 3
