MTL5573 Intrinsically Safe Isolating Temperature Converter
Description:
Manufacturer : MTL
Product No. : MTL5573
https://www.achievers-automation.com More Products
Reliable Industrial Component Sourcing for Enterprises
This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.
To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.
The MTL MTL5573 is a compact single-channel galvanically isolated temperature converter belonging to the MTL5500 series of intrinsically safe isolators, manufactured by Eaton MTL Instruments. It converts low-level temperature signals from RTD or thermocouple (THC) sensors installed in explosive hazardous zones into standard 4–20mA analog outputs for safe-side DCS, PLC and recording equipmentAlibaba.co....
This unit provides full 3-port galvanic isolation between hazardous sensor side, safe control side and power supply, eliminating ground loop interference and transient cross-coupling. It supports software-configurable linearisation, sensor ranging, fault diagnostics and cold junction compensation (CJC) for thermocouple inputs. The narrow 16mm DIN rail form factor enables high-density cabinet installation, with certified intrinsic safety approvals for Zone 0 / Class I Div 1 hazardous locations in oil & gas, chemical and pharmaceutical plants. Integrated sensor failure detection outputs configurable upscale/downscale NAMUR NE43 out-of-range signals for alarm logic systems.
Detail:
| Parameter Item |
Official MTL5573 Datasheet Value |
| Full Model Code |
MTL5573 |
| Brand |
MTL Instruments (Eaton Crouse-Hinds) |
| Channel Count |
1 single channel |
| Supported Hazardous Side Inputs |
All thermocouple types (J,K,T,E,R,S,B,N,XK); 2/3/4-wire RTD (Pt100/Pt500/Pt1000, Cu/Ni); mV low-level signals |
| RTD Nominal Excitation Current |
200 µA |
| Thermocouple Max Lead Resistance |
600 Ω |
| Cold Junction Compensation (CJC) |
Software selectable ON/OFF; CJC error ≤ 1.0 °C |
| Standard Output Signal |
4–20 mA, max load resistance 600 Ω |
| Out-of-Range Standard |
Configurable MTL or NAMUR NE43 fault characteristic |
| Calibration Accuracy (+20 °C) |
THC/mV: ±15 µV or ±0.05% input (whichever greater)
RTD: ±80 mΩ
Output: ±11 µA |
| Rejection Performance |
Common mode rejection: 120 dB (240 V 50/60 Hz)
Series mode rejection: 40 dB (50/60 Hz) |
| Power Supply Input |
24 V DC nominal (20–35 V DC operating range) |
| Max Current Consumption |
50 mA @ 24 V DC (20 mA output) |
| Max Power Dissipation |
1.2 W @ 24 V DC |
| Isolation Barrier Rating |
3-port full galvanic isolation; Um = 253 V rms / DC |
| Specification Category |
Detailed Technical Data |
| Mounting Standard |
35 mm EN 60715 standard DIN rail |
| Module Dimensions (W × H × D) |
16 mm × 99 mm × 110 mm slim compact housing |
| Net Unit Weight |
115 g |
| Housing Material |
Flame-retardant yellow thermoplastic |
| Terminal Type |
Screw clamp terminals for field instrument wiring |
| Operating Ambient Temperature |
-20 °C ~ +60 °C |
| Storage Temperature Range |
-40 °C ~ +80 °C |
| Intrinsic Safety Certifications |
ATEX Ex ia IIC T4, IECEx, FM Class I Div 1 / Div 2 |
| Hazardous Zone Compatibility |
Zone 0, Zone 1, Zone 2; Groups A-D |
| Intrinsic Safety Parameters |
Ui = 30 V, Ii = 200 mA, Pi = 1.2 W, Ci negligible |
| Diagnostic Indicator |
Yellow LED alarm for sensor break / open circuit fault |
| Configuration Method |
PC software via dedicated configuration socket |
| Industrial Compliance Standards |
EN 61010-1, EN 61326-1 EMC, RoHS compliant |
Brand
MTL (Measurement Technology Limited) is a British company focusing on industrial automation safety and explosion-proof technology. It was founded in 1955 and is headquartered in Manchester. Currently, MTL is a brand under Eaton Corporation, and is affiliated with Eaton's CrouseHinds product portfolio, focusing on providing intrinsic safety solutions for hazardous industrial environments.
As the world's leading power management company, Eaton further strengthens its competitiveness in the fields of industrial process control, explosion-proof equipment and safety grids by acquiring and integrating MTL's technology and product lines. MTL's product line (such as safety gates, isolation gates, surge protectors, etc.) has now become a core component of Eaton's industrial automation field.
