IDEC HW-U10 Control Unit Switch Module
Product Details:
Manufacturer : IDEC
Product No. : HW-U10
https://www.achievers-automation.com More Products
Reliable Industrial Component Sourcing for Enterprises
This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.
To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.
This modular base adopts panel front IP65 sealed design, suitable for installation on metal or plastic control cabinet front panels with standard 22mm round cutout. Screw-type wiring terminals provide stable anti-loose wire clamping for copper control cables, eliminating loose wiring risks under workshop vibration. Independent contact chamber structure separates low-current signal circuits to avoid cross-interference. The HW-U10 supports rapid assembly/disassembly with all IDEC HW series operation heads without auxiliary tools, realizing flexible on-site configuration of control functions.
Compliant with global IEC 60947-5-1 low voltage control device standards, UL/CSA safety certifications, wide operating temperature range adapts to machine tools, packaging equipment, conveyor control cabinets and automated assembly line operation panels. The internal silver alloy contact structure ensures stable signal switching for millions of mechanical cycles.
Detail:
| Parameter Item |
Standard Specification of IDEC HW-U10 |
| Brand |
IDEC |
| Full Model Code |
HW-U10 |
| Product Series |
HW Modular 22mm Control Switch Base Unit |
| Contact Configuration |
Single Normally Open (1NO) Contact |
| Rated Thermal Current (Ith) |
5 A |
| Rated Insulation Voltage (Ui) |
250 V AC |
| Rated Operational Voltage AC |
12 VAC ~ 240 VAC |
| Rated Operational Voltage DC |
12 VDC ~ 240 VDC |
| Minimum Contact Switching Current |
1 mA / 5 VDC |
| Dielectric Withstand Voltage |
2000 V AC (1 min between contact and housing) |
| Mechanical Service Life |
≥ 1,000,000 operation cycles |
| Electrical Service Life (Full Rated Load) |
≥ 100,000 switching cycles |
| Panel Mount Cutout Size |
Standard Φ22 mm circular hole |
| Front Panel Ingress Protection |
IP65 (fully assembled with HW series operation head) |
| Ambient Operating Temperature |
-20 ℃ ~ +60 ℃ |
| Storage & Transport Temperature |
-40 ℃ ~ +80 ℃ |
| Vibration Resistance Standard |
IEC 60068-2-6, 10–150 Hz, 0.75 mm amplitude |
| Shock Resistance Standard |
IEC 60068-2-27, 10 g peak acceleration |
| Wiring Terminal Type |
Anti-loose screw clamp terminal |
| Compatible Wire Range |
0.5 mm² ~ 1.5 mm² solid/stranded copper wire |
| Net Unit Weight |
28 g |
| Global Safety Certifications |
UL, CSA, CE, IEC 60947-5-1, RoHS |
| Component Name |
Raw Material Grade |
Functional Description for IDEC HW-U10 |
| Main Base Housing Body |
Flame-Retardant PA66 Plastic (UL94 V0) |
High dielectric insulation, impact resistance, integrated snap-fit locking structure for HW front heads |
| Fixed Contact Terminal Blocks |
Nickel-Plated Copper Alloy |
Anti-oxidation conductive terminals, stable screw wire clamping, low contact resistance |
| Movable Contact Piece |
Silver Alloy Composite Contact |
Anti-arc wear resistant, guarantees reliable micro-current signal switching for PLC input circuits |
| Contact Compression Spring |
Stainless Steel SUS304 |
Constant contact pressure to avoid poor contact under vibration and temperature fluctuation |
| Screw Fastener for Wiring Terminals |
Galvanized Carbon Steel |
Cross recess anti-slip screw design, prevents wire loosening in vibrating cabinet environments |
| Front Sealing Gasket |
NBR Oil-Resistant Rubber |
Compression seal between base and operation head to maintain IP65 front panel dust/water protection |
| Internal Isolation Partition |
Glass-Filled Insulating PBT Plastic |
Separates contact chamber and wiring cavity to prevent electric leakage and signal cross interference |
| Snap Lock Buckle |
Integrated Molded PA66 Plastic |
Quick assembly/disassembly structure, locks HW series front operation heads without extra tools |
| Terminal Insulation Cover |
Transparent PP Plastic |
Visual inspection window for wire insertion depth, prevents accidental live terminal touch |
