Telemecanique XY2-CH Cable-Operated Emergency Stop Switch
Product Details:
Manufacturer : Telemecanique
Product No. : XY2-CH
https://www.achievers-automation.com More Products
Reliable Industrial Component Sourcing for Enterprises
This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.
To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.
The Telemecanique XY2-CH belongs to the brand’s industrial cable-operated emergency stop safety switch lineup, specially engineered for long-distance machinery emergency shutdown via tensioned steel wire rope. Designed to meet global machine safety standard EN ISO 13850, this latching pull-to-trip safety device triggers immediate equipment halt when tension force is applied to the attached steel cable. After activation, the XY2-CH maintains a locked trip state and requires manual reset to resume normal operation, eliminating accidental automatic restart hazards.
Detail:
| Parameter Item |
Standard Specification of Telemecanique XY2-CH Series Base Unit |
| Brand |
Telemecanique (Schneider Electric) |
| Series Model Code |
XY2-CH |
| Product Type |
Cable-Operated Latching Emergency Stop Safety Switch |
| Governing Safety Standards |
EN ISO 13850, IEC 60947-5-1 |
| Achievable Safety Level |
PL d / Category 3 (Dual NC contact wiring) |
| Standard Contact Layout |
2 x NC Safety Contacts + 1 x NO Auxiliary Contact |
| Contact Material |
Silver Alloy with Anti-Arc Coating |
| Rated Operational Voltage AC |
24 VAC ~ 230 VAC |
| Rated Operational Voltage DC |
24 VDC ~ 250 VDC |
| Conventional Thermal Current (Ith) |
10 A |
| Rated Insulation Voltage (Ui) |
250 V |
| Minimum Trip Pull Force |
80 N |
| Max Allowable Steel Cable Length |
100 m (with proper tension support brackets) |
| Latching Feature |
Yes, mechanical lock after trip; manual reset required |
| Mechanical Service Life |
≥ 1,000,000 operating cycles |
| Electrical Service Life |
≥ 100,000 cycles under full rated load |
| Ingress Protection Rating |
IP65 (fully assembled with cable gland) |
| Ambient Operating Temperature |
-25 ℃ ~ +70 ℃ |
| Storage Temperature Range |
-40 ℃ ~ +80 ℃ |
| Shock Resistance Standard |
IEC 60068-2-27, 30 g peak acceleration |
| Vibration Resistance |
10–150 Hz, amplitude 1 mm per IEC 60068-2-6 |
| Mounting Mode |
Surface mounting via integrated housing mounting lugs |
| Net Unit Base Weight |
420 g |
| Certifications |
CE, cULus, TÜV Machine Safety Certified |
| Component Name |
Raw Material Grade |
Functional Description for Telemecanique XY2-CH |
| Outer Main Enclosure Housing |
Reinforced PA66 Flame Retardant Plastic (UL94 V0) |
Impact-resistant sealed shell, integrated mounting lugs, dust/water splash barrier for IP65 rating |
| Internal Tension Trip Mechanism |
Galvanized Carbon Steel |
Spring-loaded latching trigger, corrosion-resistant for long-term cable tension operation |
| Contact Carrier Slide Assembly |
Glass-Filled PBT Plastic |
Insulated sliding carrier to separate dual contact blocks, low friction repeated actuation |
| NC Safety Contact Terminal Blocks |
Nickel-Plated Copper + PA66 Insulator |
Vibration-proof screw terminals for safety circuit wiring, anti-loosening industrial design |
| NO Auxiliary Contact Module |
Tin-Plated Copper Conductors |
Signal feedback terminal for PLC fault monitoring and alarm indication |
| Manual Reset Actuator Knob |
Soft TPE Overmolded PA Plastic |
Ergonomic rotary reset handle, visible red safety marking for quick operator identification |
| Internal Compression Trip Spring |
Stainless Steel |
Stable consistent pull force threshold across full temperature range |
| Cable Entry Gland Interface |
NBR Rubber Sealing Gasket |
Compression seal for steel wire rope penetration, maintains IP65 integrity post installation |
| Internal Isolation Partition |
Silicone-Free FR4 Insulating Plastic |
Electrical separation between dual safety contact circuits for redundant safety performance |
Brand
TELEMECANIQUE was founded in 1924 by the founding team of the Nanterre Electrical Equipment Factory in France. They initially invented the first contactor and quickly developed into a well-known brand in the field of industrial control and automation.
. In 1928, the company was renamed "La Telemecanique Electrique" and has long been focusing on products such as contactors, circuit breakers, thermal relays, programmable logic controllers (PLC), frequency converters, push button switches and sensors.
