Balluff BK9103 PROFINET RT Bus Coupler Industrial I/O Module
Product Details:
Manufacturer : Balluff
Product No. : BK9103
https://www.achievers-automation.com More Products
Reliable Industrial Component Sourcing for Enterprises
This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.
To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.
The Beckhoff BK9103 is a high-performance PROFINET RT Class B bus coupler designed to seamlessly connect modular Beckhoff bus terminal systems with PROFINET Industrial Ethernet networks. As a core component of Beckhoff’s fieldbus terminal series, the BK9103 enables flexible, scalable industrial I/O expansion for automated production lines, building automation, and process control systems.
Detail:
|
Technical Item
|
Parameter Value
|
|
Supported Protocol
|
PROFINET RT (Class B)
|
|
Data Transfer Rate
|
10/100 Mbit/s (auto-negotiation)
|
|
Bus Interface
|
2 × RJ45 (integrated 2-channel external switch)
|
|
Transmission Medium
|
4×2 twisted pair copper cable (Cat3 for 10 Mbit/s, Cat5 for 100 Mbit/s)
|
|
Max. Bus Terminals
|
64 (255 with K-bus extension)
|
|
Max. Fieldbus Data Volume
|
512 bytes input, 512 bytes output
|
|
Max. Digital I/O Signals
|
512 inputs/outputs
|
|
Max. Analog I/O Signals
|
256 inputs/outputs
|
|
Power Supply
|
24 V DC (-15% / +20%)
|
|
Input Current
|
70 mA + (total K-bus current)/4, max. 500 mA
|
|
K-bus Maximum Current Supply
|
1750 mA
|
|
Power Contact Rating
|
Max. 24 V DC, max. 10 A
|
|
Electrical Isolation Voltage
|
500 V (power contact/supply voltage/fieldbus)
|
|
Network Topology
|
Line topology / Star topology
|
|
Single Station Distance
|
100 m between devices
|
|
Max. Cascaded Devices
|
20 units (max. 2 km total line length)
|
|
Configuration Mode
|
KS2000 software, DIP switch address setting, DHCP automatic IP acquisition
|
|
Operating Temperature Range
|
-25 °C to +60 °C
|
|
Storage Temperature Range
|
-40 °C to +85 °C
|
|
Relative Humidity
|
95% (non-condensing)
|
|
Physical & Environmental Item
|
Parameter Value
|
|
Housing Material
|
Polycarbonate (industrial high-strength flame-retardant material)
|
|
Dimensions (W × H × D)
|
51 mm × 100 mm × 69 mm
|
|
Net Weight
|
Approx. 170 g
|
|
Installation Standard
|
35 mm DIN rail mounting (compliant with EN 60715)
|
|
Protection Rating
|
IP20
|
|
Wire Connection Mode
|
Screwdriver spring actuation connection
|
|
Wire Cross-Section Range
|
Solid wire: 0.08–2.5 mm²; Stranded wire: 0.08–2.5 mm²; Ferrule wire: 0.14–1.5 mm²
|
|
Wire Stripping Length
|
8–9 mm
|
|
Vibration & Shock Resistance
|
Compliant with EN 60068-2-6 / EN 60068-2-27
|
|
EMC Performance
|
Immunity: EN 61000-6-2; Emission: EN 61000-6-4
|
|
Certifications & Approvals
|
CE, CCC, UL, ATEX, IECEx, DNV
|
|
Explosion-Proof Marking
|
ATEX: II 3 G Ex ec IIC T4 Gc; IECEx: Ex ec IIC T4 Gc
|
