Phoenix Contact 1AC/2X15DC/2/PT Switching Power Supply
Description:
Description: Phoenix
Product No. :QUINT4-PS/1AC/2X15DC/2/PT
https://www.achievers-automation.com More Products
The QUINT4-PS/1AC/2X15DC/2/PT is a high-reliability primary-switched power supply from Phoenix Contact’s renowned QUINT POWER series. Designed for low-power industrial applications (up to 100 W), it features single-phase AC/DC input, dual ±15 V DC outputs, and tool-free Push-in connections for quick integration. With preventive function monitoring, exceptional power reserves, and a compact DIN rail-mount design, this power supply delivers superior system availability while saving space in control cabinets. It excels in stability, efficiency, and protection performance, making it ideal for powering sensitive industrial equipment and sensors in harsh operating environments.
Detail:
| Input Specifications |
Input Voltage Range (AC) |
100–240 V AC (-15% to +10%) |
|
Input Voltage Range (DC) |
110–250 V DC (-20% to +10%) |
|
Frequency Range |
50–60 Hz (-10% to +10%) |
|
Inrush Current |
<15 A (at 25 °C); limited to <5 A |
|
Input Protection |
Internal 3.15 A slow-blow fuse; varistor transient surge protection |
| Output Specifications |
Nominal Output Voltage |
±15 V DC |
|
Nominal Output Current |
+15 V: 2 A; -15 V: 1.4 A |
|
Boost Capabilities |
Static: 2.5 A (+, ≤40 °C); Dynamic: 4 A (+, ≤60 °C, 5 s) |
|
Regulation Deviation |
<0.5% (static load change 10%–90%); <0.1% (input voltage change ±10%) |
|
Ripple & Noise |
≤60 mV SS (at nominal values) |
|
Overvoltage Protection (OVP) |
≤18 V DC |
| Electrical Performance |
Efficiency (Typical) |
88.8% (120 V AC); 89.4% (230 V AC) |
|
Maximum Output Power |
81 W |
|
No-Load Power Consumption |
<1.4 W (120 V AC); <2 W (230 V AC) |
|
Isolation Voltage (Input/Output) |
4 kV AC (type test); 3 kV AC (routine test) |
| Mechanical & Installation |
Mounting Type |
DIN rail mounting |
|
Connection Type |
Tool-free Push-in connections |
|
Wire Cross-Section |
0.2–2.5 mm² (rigid/flexible wires); AWG 24–14 |
|
Dimensions (L×W×H) |
90 mm × 45 mm × 106 mm |
|
Weight |
370 g |
|
Protection Class |
IP20 |
| Environmental Conditions |
Operating Temperature |
-25 °C to 70 °C |
|
Storage Temperature |
-40 °C to 85 °C |
|
MTBF (IEC 61709) |
>1,284,000 h (25 °C); >644,000 h (40 °C); >231,000 h (60 °C) |
| Compliance & Certifications |
Standards |
EN IEC 60947-5-1; RoHS compliant |
|
ECCN |
EAR99 |
