Product Details:
Manufactuer : ROSEMOUNT
Product No. : 3900VP-01-10
Product Type : General Purpose pH/ORP Sensor
Product Description
The Rosemount 3900 pH Sensor / ORP Sensor features a double junction reference that aids in the sensors' resistance to harsh environments and helps prolong sensor life. The double junction protects the reference element from poisoning ions-such as ammonia, chlorine, cyanides, and sulfides. Both sensors are made with a porous Teflon® junction. The robust ph/ORP sensor design provides reliability in a wide range of aqueous solutions found in pipelines, open tanks or ponds.
Specification:
Operating Temperature:–10° to 100°C (14° to 212°F)
Max. Operating Pressure:Maximum Pressure: 790 kPa [abs] (100 psig) at 100°C (212°F)
Materials of Construction:Stainless steel, glass, Teflon®, polyphenylene sulfide (PPS), EPDM and silicone (If selecting the ORP sensor, an additional wetted material is Platinum.)
Process Connection:Front facing: 3⁄4" and 1" MNPT; Rear facing: 1" MNPT
Features:
Extended pH sensor / ORP sensor life and protection against poisoning ions using a double junction reference
Enhanced performance and increased life with cracking resistant glass
Maximum chemical resistance provided by a rugged polyphenylene sulfide body
Operates in sub-zero temperatures down to -10°C (14°F)
Built-in solution ground for advanced diagnostics
pH/ORP sensor body features a one-piece construction with both front facing and rear facing process threads
¾” and 1” MNPT process connections to meet a variety of application installation requirements
SMART enabled for pH measurements
PARTS & ACCESSORIES:
| 11275-01 |
Handrailmountingassembly |
| 12707-00 |
Jetspraycleaner |
| 2002011 |
CPVCflow-throughtee,1½-in.nationalpipethread(NPT)processconnection |
| 23242-02 |
Mountingadapter,1½-in.insertion,1x¾in. |
| 23555-00 |
Junctionbox,Rosemount54/5081/1055/Xmtcompatiblepreamplifier |
| 24091-00 |
Cell,lowflow,¼-in.inletandoutlet |
| 33894-00 |
Adapter,1-in.NPTlowflowcell |
| 24281-00 |
15-ft.(4.6m)VP8cable |
| 24281-01 |
25-ft.(7.6m)VP8cable |
| 24281-02 |
2.5-ft.(0.8m)VP8cable |
| 24281-03 |
50-ft.(15.2m)VP8cable |
| 24281-04 |
100-ft.(30.5m)VP8cable |
| 24281-05 |
4-ft.(1.2m)VP8cable |
| 24281-06 |
10-ft.(3m)VP8cable |
| 24281-07 |
20-ft.(6.1m)VP8cable |
| 24281-08 |
30-ft.(9.1m)VP8cable |
| 9200273 |
Extensioncable,11-conduit,shielded,unprepped,perfoot |
| 9210012 |
Buffersolution,pH4.01,16oz.(473ml) |
| 9210013 |
Buffersolution,pH6.86,16oz.(473ml) |
| 9210014 |
Buffersolution,pH9.18,16oz.(473ml) |
| 00390-7101-0001 |
Lowflowpanel |
| R508-8OZ |
Oxidation reduction potential(ORP)calibration standard 460±10mV |
